AS Motor 915 Sherpa
RRP: £12,695 Loncin 21 PS
RRP: £13,895 B&S 27 PS
Fast and agile ride-on mower with limited slip differential for moderate inclines
The AS 920 Sherpa 2WD boasts work rates reaching 9,450 m² per hour, thanks to its 90 cm cutting width and choice of either a high-power Loncin 2-cylinder engine with 708 cc displacement and up to maximum of 21,7 hp, or Briggs & Stratton 2-cylinder engine with 724 cc displacement and up to 27 hp. The closed, surfing mower deck gives way upward which protects both the blade and the turf, as the blade will not come into contact with the ground. Moreover, the shape of the mower deck allows flush, close-to-the-edge mowing. The AS 920 Sherpa 2WD has a turning radius of just 65 cm.
The AS 920 Sherpa 2WD’s cross-blade system delivers impressive mulching results in grass and dense growth up to 1.5 meters high. Bearing-supported blades cut the grass while a mulching blade positioned above them shreds the cuttings, which are then deposited between the wheels for added safety on slopes and wet grass. Cutting heights can be adjusted to 5 levels from 35–135 cm with an optional mulch kit available for even finer mulching results.
Hydrostatic transmission allows the precise adaptation of speed to match the terrain, reaching 10.5 km/h and 8.2 km/h in reverse. Just one lever controls the drive, brake and parking functions for easy operation, while limited slip differential can be activated for excellent propulsion and traction when needed.
With a highly stable tubular frame, the AS 920 Sherpa 2WD performs even under harsh conditions. Operators up to 1.9 m tall can operate the machine comfortably thanks to a length-adjustable seat and seat spring package. A low centre of gravity, folding bar and branch deflectors are added safety features, while lashing points integrated in the frame enable secure transport.
Two separate ventilation circuits for the engine and hydrostatic transmission prevent overheating: the engine takes in air from above and discharges it to the side, while the hydrostatic transmission takes air from the rear and discharges it downward. This system ensures a long service life.
Product Advantages:
Surfing mulch-mower deck
Closed mower deck with AS cross-blade system. The main blade cuts, the cross-blade chops the cuttings. The surfing mower deck gives way upward on uneven terrain to protect against damage.
Ergonomic sitting position provides excellent driving comfort
Length-adjustable driver seat, innovative seat suspension and ergonomic sitting position provide comfort for tall operators during long work periods.
Small turning radius, high work rate
The turning radius of just 60 cm provides agility even on difficult terrain.
Stable tube frame
High stability and torsional rigidity with heavy load.
Terrain with moderate inclines
Performs on moderate inclines thanks to a low weight and low centre of gravity.
Variable hydrostatic transmission (ride-on mower)
Easy adaptation of the speed to every terrain with integrated, mechanical parking brake in the drive lever.
Stable, folding bar
Greater operator safety in the machine's limit area.
Technical Data:
Cutting Width: 90 cm
Engine Manufacturer: Loncin / Briggs & Stratton
Engine Designation: LC2P77F / Professional Series 8
4-Stroke Engine: 2-cyl.
Displacement: 708 cc / 724cc
Maximum Power: 21.7 PS / 27PS
Drive: 2WD Rear Wheel
Transmission: Variable Hydrostatic
Max. Speed: 10.5 km/h
Parking Brake: Automatic
Limited-slip Differential: Yes
Blade: Cross Knife
Discharge: Mulch
Cutting Height: 50 - 105 mm
Fuel Tank Capacity: 17 l
Seat Spring Package: Standard
Dimensions: L/W/H 191×98×152 cm
Weight: 284 kg / 280 kg
